3 Way NC 14.5mm OD M20 Thread Expresso Machine Solenoid Valve Stem
A solenoid valve consists of 6 components:
* The electromagnet
* The plunger
* The plunger spring
* The plunger gasket
* The main gasket
* The tube assembly
* The valve body
The tube assembly
The tube assembly is a stainless-steel cylinder that serves as a guide for the piston and spring inside. In case of a 2-way valve, this tube is capped at the end. For a 3-way valve, this end is normally open to drain the wastewater.
The plunger gasket
The plunger gasket is located in the bottom of the plunger. This gasket is a part that cannot be serviced. The gasket is compressed to a valve seat of the valve body to seal it.
The plunger
The plunger is made of ferritic stainless steel (this is a magnetic stainless-steel variant, opposed to commonly used “traditional” stainless steel, which is not magnetic). This plunger has a gasket in the bottom to seal the valve seat. On top of the plunger, there is a neck in which the spring is located.
Detailed Images of solenoid valve stem:
Dimension & Data of solenoid valve stem:
| Dimension | Model | |
 | Function | |
| Seat Connection | |
| Core Tube Material | |
| Seal Material | |
| Voltage | All range of AC and DC available |
| Customize Service | Provided, Pls show us sample or drawing |
Brando Solenoid Valve Stem Production Video:
Solenoid Valve Stem Categories:
*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 30mm.
*According to tube material: Brass, Stainless Steel
*According to valve application: Our armatures are widely used in pneumatic, hydraulic, fluid control fields, covering textiles, home appliances, automobiles, refrigeration, dust collector and other automation control industries.
Features of Armature Assembly:
The main characteristics of the armature of solenoid valve can be reflected in the following aspects.
1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive
2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.
3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance
4. Sealing materials can be selected according to your different requirements
5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
